- screw terminals
- highly heat resistant contact carrier
- nickel plated contacts
- enclosure base with stamped recess for quick cutting out
- Ampere 16 A
- Poles 7 p
- Voltage 400 V
- Earth position 6 h
- Hertz 50-60 Hz
- Protection type IP 44
